MSB7800-ES2F 36 Port Mellanox Ethernet Switches High Performance
उत्पाद विवरण:
| ब्रांड नाम: | Mellanox |
| मॉडल संख्या: | MSB7800-ES2F |
| दस्तावेज़: | MSB7800-ES2F.pdf |
भुगतान & नौवहन नियमों:
| न्यूनतम आदेश मात्रा: | 1 टुकड़ा |
|---|---|
| मूल्य: | Negotiate |
| पैकेजिंग विवरण: | बाहरी डिब्बा |
| प्रसव के समय: | इन्वेंट्री के आधार पर |
| भुगतान शर्तें: | टी/टी |
| आपूर्ति की क्षमता: | परियोजना/बैच द्वारा आपूर्ति |
|
विस्तार जानकारी |
|||
| आवेदन: | सर्वर | स्थिति: | नया और मूल |
|---|---|---|---|
| स्विच करने की क्षमता: | 2.6 टीबीपीएस | अपलिंक कनेक्टिविटी: | 200 जीबीपीएस |
| नाम: | MSB7800-ES2F 36 पोर्ट मेलानॉक्स ईथरनेट स्विच | कीवर्ड: | मेलानॉक्स ईथरनेट स्विच |
उत्पाद विवरण
NVIDIA Switch-IB 2 MSB7800-ES2F 100Gb/s InfiniBand Switch
High-Performance Data Center Networking Solution
The MSB7800-ES2F represents the pinnacle of InfiniBand switching technology, delivering exceptional performance for demanding HPC and AI workloads. This advanced network card solution provides the foundation for next-generation data center infrastructure.
Key Advantages:
- 36 ports of 100Gb/s InfiniBand connectivity
- 7.2Tb/s aggregate bidirectional throughput
- NVIDIA SHARP™ in-network computing technology
- Ultra-low latency for superior application performance
- Comprehensive management with MLNX-OS
- Energy-efficient design with redundant power
Product Overview
The MSB7800-ES2F, also known as mq9700 in some configurations, is a high-density 100Gb/s InfiniBand switch engineered for modern data centers. This powerful network card solution delivers exceptional performance for high-performance computing, artificial intelligence, and machine learning applications. With 36 non-blocking ports in a compact 1U form factor, it provides the scalability and reliability required by today's most demanding workloads.
Key Features
Performance Excellence
36 non-blocking 100Gb/s ports delivering 7.2Tb/s aggregate throughput with ultra-low latency for maximum application performance.
In-Network Computing
NVIDIA SHARP technology offloads collective operations from CPUs to the switch, dramatically accelerating MPI operations.
Operational Efficiency
Power-optimized design consuming as low as 122W with redundant, hot-swappable power supplies and cooling modules.
Core Technology
The MSB7800-ES2F leverages NVIDIA's Switch-IB 2 technology with integrated Scalable Hierarchical Aggregation and Reduction Protocol (SHARP). This innovative approach to network card design implements in-network computing by performing data aggregation within the switch fabric itself. The technology significantly reduces the number of data traversals required for collective operations, freeing CPU resources for computation rather than communication processing.
This advanced nic card solution incorporates an Intel Celeron 1047UE dual-core processor running MLNX-OS, providing comprehensive chassis management capabilities. The integration with NVIDIA UFM platforms enables real-time network telemetry with AI-powered analytics for proactive infrastructure management.
Working Principle
The MSB7800-ES2F operates as a high-performance InfiniBand switch with integrated computing capabilities. When deployed in HPC or AI clusters, the switch:
- Receives data packets from connected nodes through its 36 QSFP28 ports
- Processes MPI collective operations directly within the switch using SHARP technology
- Reduces network congestion by performing data aggregation at the network level
- Routes optimized data packets to destination nodes with minimal latency
- Continuously monitors network health and performance through integrated management
This network card architecture fundamentally changes data center communication patterns by moving computation into the network infrastructure.
Application Scenarios
The mq9700 platform excels in multiple high-performance computing environments:
- Artificial Intelligence & Machine Learning: Training clusters requiring high-bandwidth, low-latency interconnects
- High-Performance Computing: Scientific simulations, financial modeling, and research applications
- Cloud Infrastructure: High-density virtualization environments and scale-out storage
- Big Data Analytics: Real-time processing of massive datasets across distributed systems
This versatile nic card solution serves as an ideal top-of-rack switch for small to extremely large cluster deployments, supporting various network topologies including fat-tree, torus, and hypercube configurations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Port Configuration | 36 x 100Gb/s QSFP28 ports |
| Aggregate Throughput | 7.2Tb/s bidirectional |
| Form Factor | 1U rack mount |
| Power Supply | 1+1 redundant, hot-swappable |
| Power Consumption | 122W (ATIS weighted, fully populated) |
| Management | MLNX-OS, RJ45, RS232, USB |
| Processor | Intel Celeron 1047UE dual-core |
| Memory | 4GB DDR3 RAM, 16GB SSD |
| Dimensions | 1.7" H × 16.85" W × 27" D |
| Weight | 11.978 kg (26.4 lbs) |
Ordering Information
| OPN | Description | Airflow |
|---|---|---|
| MSB7800-ES2F | Switch-IB 2 100Gb/s InfiniBand switch, 36 QSFP28 ports, dual power supplies | Port-to-Chip (P2C) |
| MSB7800-ES2R | Switch-IB 2 100Gb/s InfiniBand switch, 36 QSFP28 ports, dual power supplies | Chip-to-Port (C2P) |
| MSB7880-ES2R | Switch-IB 2 100Gb/s InfiniBand router, 36 QSFP28 ports, dual power supplies | Chip-to-Port (C2P) |
| MSB7880-ES2F | Switch-IB 2 100Gb/s InfiniBand router, 36 QSFP28 ports, dual power supplies | Port-to-Chip (P2C) |
Competitive Advantages
The MSB7800-ES2F offers several distinct advantages over conventional switching solutions:
- In-Network Computing: SHARP technology provides up to 4x acceleration for MPI operations compared to traditional network card approaches
- Energy Efficiency: Advanced power management reduces operational costs with industry-leading performance-per-watt
- Scalability: Support for extremely large cluster deployments with consistent low latency across all ports
- Comprehensive Management: Integration with NVIDIA UFM platform for AI-powered network analytics and proactive maintenance
- Proven Reliability: Enterprise-grade components with redundant, hot-swappable power and cooling subsystems
This mq9700 compatible network card delivers exceptional value for organizations deploying high-performance computing infrastructure.
Service & Support
We provide comprehensive service packages to ensure optimal performance of your InfiniBand infrastructure:
- Warranty: Standard 3-year hardware warranty with optional extensions
- Technical Support: 24/7 customer consultation and technical assistance
- Delivery: Large inventory ensures prompt shipment with various logistics options
- Integration Services: Professional deployment assistance and configuration optimization
- Software Updates: Regular firmware and management software updates
Frequently Asked Questions
What is the difference between the MSB7800-ES2F and other models in the series?
The MSB7800-ES2F features Port-to-Chip (P2C) airflow direction, while the ES2R variant uses Chip-to-Port (C2P) airflow. This nic card selection depends on your data center cooling configuration.
What type of cables are compatible with the QSFP28 ports?
The switch supports various 100Gb/s connectivity options including DAC, AOC, and optical transceivers with appropriate fiber cables. This network card solution offers flexibility in cabling infrastructure.
How does SHARP technology improve application performance?
SHARP offloads collective operations from server CPUs to the switch network, reducing data traversals and MPI operation time by up to 4x compared to traditional approaches.
What management options are available for this switch?
The MSB7800-ES2F can be managed through MLNX-OS command line, web interface, or integrated with NVIDIA UFM for enterprise-scale deployment management.
Is this switch compatible with existing InfiniBand infrastructure?
Yes, this mq9700 compatible network card maintains backward compatibility with earlier InfiniBand generations while delivering enhanced performance for modern workloads.
Installation & Operational Notes
Important Considerations
- Ensure adequate clearance for airflow (front-to-rear or rear-to-front as specified)
- Verify power requirements: 100-127VAC or 200-240VAC with 80 Plus Gold efficiency
- Maintain operating temperature between 0°C to 45°C with 10-85% non-condensing humidity
- Follow ESD precautions during installation and maintenance procedures
- Plan for appropriate rack mounting with included rail kit
- Ensure compatibility with existing network card infrastructure and cabling
The switch complies with CE, FCC, VCCI, ICES, RCM emissions standards and RoHS, CS, cTUVus, CE, CU safety certifications.
